Vertex III On-Wall Speakers

Vertex III OW-VJ63M On-Wall Speaker

Bringing Elac Core Technologies to Custom Audio

Designed for performance and compatibility, the Vertex III Custom Series carries the same sonic signature as our Home Audio Speakers. This means you can combine components to meet the needs of every environment, and deliver exceptional audio experiences. Whether it’s building a home theater with Vela Front Channels and On-Wall Surrounds—or In-Ceiling Atmos combined with our flagship Vertex Soundbars—it will all sound great together.

Wall

Mounting

Horizontal and Vertical mounting is facilitated with 4 recessed keyhole inserts. Routed channels provide easy cavity for wires to allow flush mounting to wall

Flexible

Tuning

A switch located in rear of the cabinet modifies the tuning of the tweeter to facilitate Vertical or Horizontal mounting.

Wall Mounting

Alternative

Supplied brackets can be used to hang the speakers both in the vertical and horizontal position.

AS Technology

Crystal Membrane

The The eye-catching surface of the crystal membrane is more than just an attractive design feature.

Increased stiffness through crystal shape of aluminum cone
Extended frequency range (XR), smooth roll-off
Excellent large signal behaviour
Minimized VAS, (lot of bass out of small cabinets)

JET Technology

JET 5

Air Motion Transformer principle

Linear Frequency response > 50 kHz
Extended lower frequency range
Efficiency 92 dB / W / m
Improved signal accuracy

The inimitable JET tweeter

JET 5

ELAC’s JET 5 tweeter is used throughout our loudspeaker range. This high-frequency driver enthralls with its lightning-fast response and wide dynamic range, offering minimal distortion, lots of headroom and a distinctly wider frequency range than conventional dome tweeters. The ELAC JET tweeter is one of the most legendary tweeters in the industry and has won international praise with its transparent and effortless sound image.

Speaker type2 1/2-way, sealed cabinet
TweeterJet Folded Ribbon
Woofers2x6
Crossover frequency450 / 2,400 Hz
Frequency response42 to 50,000 Hz
Sensitivity88 db at 2.83 v/1m
Recommended amplifier power40 to 200 Watts
Nominal/peak power handling120/160 Watts
Nominal impedance4 Ohm
FinishBlack baffle
GrilleBlack Fabric Grille
Wall mount bracketsIncluded
DimensionsH: 33.54 in / 852 mm W: 9.76 in / 248 mm
Mounting depth3.82 in / 97.0 mm
Vertex III series Sales Sheet Version: 1.0.0 (English) Download
